Rapid Chloride Ion Permeability Testing

( RCPT )(AK-DIGI08PT)

Our rapid chloride ion permeability testing ( RCPT ) machine is designed to meet the standard of ASTM C 1202, ensuring accurate and reliable results for your testing needs. With the capability to test multiple samples simultaneously, our machine offers efficiency and convenience for your laboratory. Whether you are in the construction industry or involved in materials research, our product provides the precise measurements required to assess the chloride ion permeability of concrete and other materials. Trust in our machine to deliver consistent and trustworthy results, helping you make informed decisions about the durability and longevity of your materials. Invest in quality and precision with our rapid chloride ion permeability testing (RCPT) machine.

AK-DIGI08 is a simple budget friendly machine for small laboratories. It requires manual data observer.

8-Channel RCPT (Model: AK-DIGI08PT)

6-Channel RCPT (Model: AK-DIGI06PT)

3-Channel RCPT (Model: AK-DIGI03PT)

4-Channel RCPT (Model: AK-DIGI04PT)

Available Variants

Gallery

Provide a short description of the gallery, highlighting key things.

Videos

Or someone else will hire you to build theirs. Here is how you can take action – starting today.

Features

Up to 8-Channel unit for testing simultaneously.
230V AC / 50Hz power supply.
Short-circuit protection fuse.
User adjustable voltage: 56 - 65V DC.
Maximum testing current for protection: 500mA per channel.
Current accuracy 0.5% at 1 to 500mA.
Voltage accuracy 0.1V at 60V.
Dimensions: 300mm*300mm*145mm.

gray concrete wall inside building

gray concrete wall inside building

Plexiglass Cells (ASTM C 1202)

Cell Material: Plexiglass.
Tank Dimensions: 150mm*50mm*150mm.
Brass Screen Thickness: 0.5mm thick.
Rubber Washer: OD=105mm, ID=89mm.
Rubber Washer Thickness: 4mm.
Threaded Rod Material: Stainless-Steel.
Threaded Rod Size: M8 200mm.
Washer, Nut Material: Stainless-Steel.

white and black abstract painting

white and black abstract painting

Accessories

Connecting Cable: 4mm Silicone Insulation.
Connecting Cable Length: 1.5mtrs.
Spare Fuse: 500mA (1-Box).
Power Cord: 2mtrs.
Data Cable: Male USB A to Male USB B.
Sodium Chloride (Nacl): 500gms.
Sodium Hydroxide (NaOH): 500gms.
Software Pen drive.
Spanners.
Cleaning Brush.
Funnel.

worm's-eye view photography of concrete building

worm's-eye view photography of concrete building

8-Channel RCPT (AK-DIGI08) -1
Plexiglass Cells -16
Stainless-Steel Threaded Rods - 32
Stainless-Steel Nuts - 64
Stainless-Steel Washers - 64
Connecting Cables RED - 8
Connecting Cables BLACK - 8
Power Cord - 1

Spare Fuse Box (500mA) - 1 (20 Pieces)
Sodium Chloride - 500gms
Sodium Hydroxide - 500gms
Spanners - 2
Cleaning Brush - 1
Funnel - 1
User Guide - 1

Packing List (8-Channel)
